Talking Signs. Create your own interactive Talking Signs, Talking Posters and Audio Signs using visual information and sound to deliver your message more effectively. The PIR sensor will detect someone approaching the area which will activate an audible voice message.
APPLICATIONS:
Ideal for producing Health and Safety Talking Posters. Use in the workplace, Care Homes, Schools, Colleges, Universities, factories, shops and reception areas. A unique solution to enhance compliance behaviour.
Raise attention in critical areas and remind people of important procedures. Overcome sign blindness with this unique signage solution. Talking Posters are proven to be more effective than conventional signs that just use visual information.
Battery powered and no wiring required. No special tools needed for installation. Options for mains power if required for use in busy locations.
FEATURES:
- Automatic audio playback after the PIR sensor has been activated
- Record your own voice message using the built-in microphone
- Option to download your own custom MP3 voice messages, sound effects or alerts
- Update and change your messages as many times as you wish
- High quality MP3 sound output
- Unit will store multiple MP3 files to enable a looped playback
- Three volume settings: Low, Medium and High
- Battery powered, and no wiring required
- No special tools needed for installation
- Wall mounting holes
- Includes an optional wall mounting bracket
SPECIFICATIONS:
- Two playback settings: Single Track or Multiple Tracks
- In Multiple Track Mode one track will play after each activation, (in file name order)
- Multiple Track Mode will NOT playback randomly
- Two power supply options: 3 x AAA Batteries or Mains Power Adapter, (bought separately)
- Micro USB Socket to support a 5 Volt DC Power Adapter
- File transfer using the built-in Micro USB socket and cable supplied
- Audio playback format: MP3 format only
- Sensor activation distance: Up to 4 metres with a 120 Deg Angle
- PIR Sensor is effective in all light conditions, including complete darkness
- Volume Level: 90 dB maximum, (depending on original recording)
- Size: 96 x 60 x 25mm
- Internal Memory: 4MB
- Recording time: Approx 4 minutes, (calculated at 128Kbps MONO bitrate)
- Recording time can be doubled to 8 minutes by changing the MP3 file sample bitrate to 64kbps. (See notes below)
- Battery Life: This will depend on the mAh rating of the batteries that you install. As an example, based on batteries with a capacity between 500-1000 mAh, a 5 second message will playback between 3,600 and 7,200 times. We always recommend that you use high quality branded alkaline batteries.
User Guide
NOTE: If you are located in the EU or USA, please note that stock is available locally from our Amazon Store with Prime delivery.
Click link Amazon Germany . (Also available from other local Amazon websites in the EU)
Click link Amazon USA . (Can also ship to Canada and Mexico).
What is PIR?
PIR stands for Passive Infrared. A PIR Sensor is an electronic sensor that measures infrared light radiating from objects in its field of view. All objects with a temperature above zero emit heat energy in the form of radiation. Usually this radiation is invisible to the human eye because it radiates at infrared wavelengths, but it can be detected by PIR Sensors. PIR sensors don't detect or measure heat, but instead they detect the Infrared radiation emitted from an object. A PIR-based motion detector is used to sense movement of people, animals, or other objects. They are more commonly used in burglar alarms and automatically-activated lighting systems.
What is the difference between normal Motion Sensors and PIR Sensors?
PIR Sensors do not detect motion, instead they detect abrupt changes in temperature at a given point using the Infrared radiation level. As an object, such as a human, passes in front of the background, such as a wall, the temperature at that point will rise from room temperature to body temperature, and then back again. This quick change triggers the detection.
Playback calculations based on the 4MB of memory
A playback time of 8 minutes can be achieved with an MP3 file that has a Bitrate value of 64Kbps.
A playback time of 4 minutes can be achieved with an MP3 file that has a Bitrate value of 128Kbps.
A playback time of 2 minutes can be achieved with an MP3 file that has a Bitrate value of 256Kbps.
